مانیتور علائم حیاتی PC-ECG
سیستم فوق کاملا PC - Base بوده و بر روی یک کامپیوتر یا لپ تاپ اجرا می گردد. Simultaneous Acquisition of 12 leads ECG Print on A4 paper using a laser printer USB computer interface with patient isolation Integrated defibrillation protection Pace pulse and Lead-off detection ECG signal and Patient management system Long storage of signals on hard disk or CD Compact and Portable
:Technical characteristics
Input circuit: Floating system ECG lead: Standard 12-Lead Baseline control: Automatic position Input impedance: ≥ 20MΩ Input current circuit: ≤1 µA Calibration Voltage: 1mV Skin Voltage tolerance : ±300mV CMRR: ≥80db Time constant: >3.2s Gain: 5, 10, 20 mm/mV Frequency response: 0.05Hz-150Hz (-3dB) Hum filter: 50Hz EMG filter: 25Hz, 35Hz Drift filter: 0.2Hz A/D conversion: 24bit Sampling rate: 500Hz, 2ms Print speed: 12.5, 25, 50 mm/s (Safety (IEC 60601-1 Type of protection: Class I and the internal power source Degree of protection: Type CF applied part :Power requirement Power supply : +5V DC by USB interface Power consumption: 1W :Dimensions , Weight Dimensions: 170mm × 100mm × 30mm Weight: 200g :Environmental condition Temperature: 10 °C to 40 °C Humidity: 25% to 95% Atmospheric pressure: 700hPa to 1060hPa
